Characterization of Textile Grade Novel Bauhinia Vahlii Fiber
Goutam Bar a,b and Kavita Chaudharya
aDepartment of Design, Banasthali Vidyapith, Banasthali, Rajasthan, India; bDepartment of Textile Design, National
Institute of Fashion Technology, Bhubaneswar, India
ABSTRACT
Increasing demand for bio-degradable, eco-friendly, and sustainable textile
products to confront environmental pollution accelerates the research on
natural fibers. Researchers are also in search of novel natural fibers to be used
in different textile products. The present study attempts to extract textile-
grade novel Bauhinia vahlii fibers (BVFs) from the Bauhinia vahlii (BV)
plant bark. Textile grade BVFs were obtained by treating the BV plant
bark with 15% (w/w) sodium hydroxide solution (NaOH) at 95°C for 2 h,
followed by manual fiber extraction. The extracted BVFs were analyzed
for physical, chemical, morphological, structural, mechanical, and thermal
characteristics. Fourier transform infrared (FTIR) spectroscopy and chemi-
cal analysis revealed that the extracted fiber contains 75.8% holocellu-
lose and 13.7% lignin. The physical analysis demonstrated that BVFs have
10.5% moisture content, 1.47 gm/cm3 fiber density, and 15.77 microns
average fiber fineness. X-ray diffraction (×RD) confirmed that BVFs have
56% crystallinity. Thermogravimetric study revealed that the BVFs could
be thermally stable up to 233.4°C. Outcomes of all the analyzes indicate
that the extracted fiber can be used to convert them into yarn by
blending with some short-staple fiber.
摘要
为应对环境污染, 人们对可生物降解、环保和可持续的纺织品的需求不断
增加, 这加速了对天然纤维的研究. 研究人员也在寻找用于不同纺织产品的
新型天然纤维. 本研究试图从紫荆（BV）植物树皮中提取纺织级新型紫荆
纤维（BVF）. 通过在95°C下用15%（w/w）氢氧化钠溶液（NaOH）处理
BV植物树皮2小时, 然后手动提取纤维, 获得纺织级BVF. 对提取的BVF进行
物理、化学、形态、结构、机械和热特性分析. 傅里叶变换红外光谱和化
学分析表明, 提取的纤维含有75.8%的全纤维素和13.7%的木质素. 物理分
析表明, BVF的含水量为10.5%, 纤维密度为1.47 gm/cm3, 平均纤维细度为
15.77微米。X射线衍射（XRD）证实BVF具有56%的结晶度. 热重分析表明,
BVF的热稳定性可达233.4°C. 所有分析的结果表明, 提取的纤维可以通过与
一些短纤维混合而转化为纱线.
KEYWORDS
Bauhinia vahlii fiber;
morphological
characterization; x-ray
diffraction; thermal analysis;
FTIR analysis; tensile strength
关键词
紫荆纤维; 形态表征; X射
线衍射; 热分析; 分析; 抗拉
强度
Introduction
The story of natural fibers used by humans dates back to prehistoric times to endure adverse weather
conditions. Until around a century ago, the only fibers used by human beings were natural to beautify
the environment and for clothing. Humans made advancements with time in the realm of textiles and
developed synthetic fibers. In the last 50 years, the production of synthetic fibers has increased
significantly and captured the textile market for their low cost, uniform quality, and excellent
durability. However, synthetic fibers are non-biodegradable and provide less comfort compared to
natural fibers. Moreover, issues like increasing carbon footprint, climatic changes, and environmental
CONTACT Goutam Bar goutam.bar@nift.ac.in Department of Textile Design, National Institute of Fashion Technology,
Bhubaneswar, India
JOURNAL OF NATURAL FIBERS
2022, VOL. 20, NO. 1, 2143464
https://doi.org/10.1080/15440478.2022.2143464
© 2022 The Author(s). Published with license by Taylor & Francis Group, LLC.
This is an Open Access article distributed under the terms of the Creative Commons Attribution License (http://creativecommons.org/licenses/by/4.0/),
which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
http://orcid.org/0000-0001-7620-4307
http://www.tandfonline.com
https://crossmark.crossref.org/dialog/?doi=10.1080/15440478.2022.2143464&domain=pdf&date_stamp=2022-12-12
pollution due to manufacturing, usage, and disposal of excessive synthetic textile materials have
emerged (Ramasamy and Subramanian 2021). Since then, customer demand for biodegradable
and sustainable textiles has grown considerably. Manufacturers are thus focusing on products
manufactured from bio-based renewable resources, i.e., from natural fibers. Plants are the
primary source of natural fibers. Researchers are also working on different natural fiber-based
products and searching for novel plant-based natural fibers to neutralize people’s growing
concerns about sustainability.
Bauhinia vahlii (BV) is a fast-growing, woody climber of the legume family. It is also among the
most abundant Indian bauhinia species, as shown in Figure 1. Bauhinia recemosa, the other name of
the BV plant, is generally found in the world’s warmer regions, mainly in Asia, Africa, and South
America (Chauhan and Saklani 2013). In India, this plant is native to the sub-Himalayan region as well
as Chhattisgarh, Madhya Pradesh, Bihar, Odisha, and West Bengal. Bauhinia vahlii plant leaves are
used to make plates and bark to make simple household products by the tribal people of Odisha for
their livelihood. Leaves and bark extract of the BV plant have potential antioxidant and antimicrobial
properties (Bar and Bar 2020).
Lignocellulosic fibers are a naturally occurring composite in which cellulosic fibrils are embedded
in the lignin matrix. Besides cellulose, lignin, hemicellulose, pectin, and wax are the other significant
components of lignocellulosic fibers (John and Thomas 2008). Hemicellulose is highly hydrophilic and
undergoes easy dissolution under alkaline conditions. Lignin is considered as a three-dimensional
copolymer comprising aliphatic and aromatic compounds. The main problem with lignin chemistry
is that it cannot be isolated to its native state. It is entirely amorphous and hydrophobic and becomes
soluble under hot alkaline conditions (Olesen and Plackett 1999). Conventionally, lignocellulosic
and bast fibers were extracted through the water retting process. Dew retting is also an alternative
and sustainable way of lignocellulosic fiber extraction. However, due to longer time requirements
and water pollution problems in water retting, researchers developed alternative fiber extraction
methods, including decortication, post decortication cleaning, enzymatic retting, chemical retting,
etc. To get better fiber quality and higher fiber yield, single or multiple methods can be employedto
extract the lignocellulosic fiber depending on the fiber type. In the case of fibers having higher lignin
content, to scrape away excess lignin from the fiber, degumming is carried out to convert them into
a textile-grade fiber. Degumming includes alkali, acid, and emulsion treatments (Kale, Alemayehu,
and Gorade 2020).
Initial attempts have been made to extract the BVFs from the BV plant bark for fiber-reinforced
composite. Kumar et al. (2021) manually extracted the fiber bundles from the BV plant bark and
treated them with 5% NaOH solution for 8 h at ambient temperature for surface modification.
Bauhinia vahlii mat reinforced composite was developed from the treated fiber strand. Stalin and
Ramkumar (2015) have prepared Bauhinia recemosa fiber-reinforced polyester composites from the
dried and staple Bauhinia recemosa plant bark of 30 mm in length. Ray et al. (2020) have also extracted
BV fiber strands by hammering the BV bark, followed by surface modification. Till now, BVFs have
been extracted in significantly coarser fiber strand form and used for making fiber-reinforced
composite only. According to the available literature, no effort has been made to extract textile-
grade BV fibers. There is a huge scope to explore this fiber further for use in textile products. The
present study focuses on the extraction and characterization of textile-grade BVFs fiber from BV bark.
Characterization of the fiber includes physical, chemical, morphological, structural, mechanical, and
thermal analysis.
Material and methods
Materials
Bauhinia vahlii plant bark was supplied by District Rural Development Agency, Mayurbhanj, Odisha,
India. Sodium hydroxide and acetic acid are used of Rankem, Maharashtra, India.
2 G. BAR AND K. CHAUDHARY
Fiber extraction process
To extract BV bast fiber, at first barks were sliced into 30–40 centimeters in length. Bark pieces were
manually cleaned to remove the immature and woody parts, followed by dipping them into the water
for 1 day at ambient temperature to soften the bark structure. Soft bark samples were treated with 15%
(w/w) NaOH solution at around 95°C for 2 h to remove the lignin and other contaminants.
Causticized samples were washed and passed through the padding mangle at a pressure of 3 bar to
squeeze out the gummy substances from the bark. The squeezing process was repeated twice, followed
by washing at 100°C for 30 min. The washed bark samples were neutralized with acetic acid. The final
removal of leftover gummy substances from the bark was carried out by scraping with a teaspoon or
simple knife. At this stage, the presence of impurities and gummy substances was minimal. The fiber
layers were separated manually from the processed bark. Dried fiber layers were cut into a length of
approximately 5 cm, and further fiber strands were separated in a width-wise direction. The extracted
fiber was further opened by hand carding. The process sequence of fiber extraction is shown in
Figure 2.
Physical property analysis
Mean fiber length was determined by randomly selecting 100 fibers from a tuft of BV fiber sample.
Each fiber sample was straightened and the length was measured using a measuring scale. Mean fiber
length, standard deviation (SD), and coefficient of variation (CV) were calculated from the measured
fiber length. The fineness of the BVFs was determined utilizing an optical fiber diameter analyzer
(OFDA 4000, BSC Electronics, Australia). The density of the BVFs (ρf) was quantified according to the
ASTM-D3800–99 method using the below equation (Tamanna et al. 2021). A tuft of BVFs was
weighed in air and subsequently in methanol using a 0.5 mm diameter copper suspension wire:
Figure 1. Image of Bauhinia vahlii plant.
JOURNAL OF NATURAL FIBERS 3
ρf ¼
W3 � W1ð Þρl
W3 � W1ð Þ � ðW4 � W2ð Þ
(1)
where W1, W2, W3, and W4 are the weight of copper wire in the air, copper wire in liquid up to the
immersion point, fiber tuft along with copper wire in the air, and fiber tuft along with suspension wire
in liquid, respectively. The specific density of methanol (ρl) is 0.79 g/ml.
Morphological characterization
A SEM (Zeiss, EVO 50) at different magnification levels was operated at 20 kv accelerating voltage to
examine surface morphology and cross-sectional view of BVFs. For cross-sectional view, fibers were
inserted inside a cork with the help of a sharp needle. Then, the cork and the fibers were finely sliced
perpendicular to the axis of the fibers using a sharp blade. A thin layer of gold coating was applied to
the fiber sample to avoid the accumulation of electrical charges.
Fourier transform-infrared analysis
The FTIR spectra of the BVFs were captured on a thermo FTIR (model Nicolet iS-50) from 400 to
4000 cm−1 wavenumber to detect the functional group present in the fiber. A KBr pallet was prepared
by mixing and compressing one part of finely chopped BVFs powder with nine parts of KBr, and it was
used for FTIR analysis.
X-ray diffraction analysis
The crystallinity index (CI) of BVFs was estimated using an X-ray diffractometer (×’pert PRO,
PANalytical) with a scanning velocity of 2 degrees/minute and an X-ray of 0.154 nm wavelength.
Finely crushed BVFs powder was used for the analysis. The crystallinity index of BVFs was computed
using the area method as per the equation below (Ling et al. 2019):
(a) (b) (c) (d)
(e) (g) (f) (h)
Figure 2. Stepwise extraction process of BVFs: (a) collected BV bark, (b) treating with NaOH solution at 95°C, (c) removal of the
gummy substance by scraping with a simple knife, (d) separation of fiber layers, (e) fiber layer cut into smaller pieces, (f) manually
extracted fiber, (g) hand carding of the fiber, and (h) final fiber after hand carding.
4 G. BAR AND K. CHAUDHARY
CI ¼
ACrystalline
ATotal
X100 (2)
OriginPro software was used to measure the area underneath the crystalline peak region (ACrystalline)
and total area (ATotal) beneath the X-ray spectra. The interplanar spacing of BVFs was estimated at
various lattice planes employing Bragg’s equation (Kumar and Das 2016):
nλ ¼ 2dhklsinθ (3)
where dhkl stands for an interplanar distance of hkl crystallographic planes, θ signifies Bragg’s angle, λ
symbolizes the X-ray wavelength, and n defines the diffraction order. The crystallite size (CS) of the
BVFs was determined using Scherrer’s equation (Elenga et al. 2009):
CS ¼
Kλ
βcosθ
(4)
where K is Scherrer’s constant having a value of 0.89, β stands for peak’s full-width at half-maximum
in radian.
Chemical analysis
Bauhinia vahlii fiber was analyzed to determine their chemical components, using the process
mentioned by Sengupta, Mazumdar, and Macmillan (1958). The acid-insoluble klason lignin
was quantified using the TAPPI method (T 222 om-06). Pectin was isolated from the BVFs by
treating the fiber with ethylene diamine tetraacetic acid at boiling temperature for 45 min (Wang
et al. 2015). The moisture content percentage of BVFs was calculated using the below formula
(Sathishkumar et al. 2013):
Moisture content %ð Þ ¼
Initial weight of the fiber � Oven dry weight of the fiber
Initial weight of the fiber
X100 (5)
Mechanical characterization
The tensile strength and breaking elongation of BVFs were measured using a tensile tester (Vibrodyn
500, Lenzing Instruments) as per the standard (ASTM D3822-01) with a gauge length and crosshead
speed of 10 mm and 0.1 mm/minute, respectively. Twenty fibers were tested, having a fiber length of
25–30 mm, and their diameter was assessed in three distinct places using digital projection of
paramount (Bar et al. 2021).
Thermogravimetric analysis
The thermal properties of the BVFs were studied by thermogravimetric (TG) and derivative thermo-
gravimetric (DTG) assessment using a simultaneous thermal analyzer SDT650. The test was carried
out for BVFs from ambient temperature to 750°C with a 10°C per minute scanning rate. OriginPro
software calculated initial and maximum decomposition temperatures,weight loss percentage, and ash
content. The kinetic activation energy (Ea) of BVFs was calculated according to the Broido’s equation
as mentioned below (Md et al. 2022):
ln ln
1
y
� �� �
¼ �
Ea
R
� �
1
T
� �
þ K
� �
(6)
where y represents normalized weight [ratio of weight at any temperature to initial weight], R is the gas
constant (8.314 J/mol K), T is the temperature in Kelvin, and K is the constant of the reaction rate.
JOURNAL OF NATURAL FIBERS 5
Results and discussion
Physical property analysis
Fiber length and fineness are the two important characteristics of any staple fiber for their spinnability.
The lengths of BVFs vary from 9 to 32 mm, with an average value of 20.05 mm. The average length of
BVFs is slightly shorter than the cotton (20–35 mm) fiber (Wang and Wang 2009). Figure 3 depicts the
distribution of fibers length of randomly selected 100 BV fibers. The SD and CV of the measured fibers
are 5.67 mm and 28.28%, respectively. Figure 4 demonstrates the distribution of BV fibers’ fineness.
The fineness of 95% BV fibers ranges from 4 to 34 microns, with an average fiber fineness of 15.77
microns comparable to the cotton fiber (12–38 microns). Only 5% of fibers are coarser than 33.57
microns. The calculated spin fineness of BVFs is below 25.6 microns, with 91.8% of fibers falling within
this limit. The comfort factor of the BVFs as per the mean fiber fineness is 93.8%, as quantified using
an optical fiber diameter analyzer. The average aspect ratio of BVFs is 1271, more than the minimum
fiber length to diameter ratio required to convert the fibers into yarn. The density of BVFs is 1.47 gm/
cm3 as determined using Archimedes’ buoyancy method. It is very close to that of other cellulosic
fibers, such as cotton, jute, hemp, flax, sisal, and nettle. Comparative data of fiber fineness and fiber
density are tabulated in Table 1.
Morphological characteristics
Figure 5 depicts a SEM image of BV fibers extracted with 15% NaOH at 1500X magnification. The
causticizing process removed a considerable amount of lignin and pectin from the fiber matrix,
enabling the fibers’ separation, as seen in the image (Kumar and Das 2016). Though the
maximum impurities have already been removed from the fiber surface, surface roughness,
and fragmented impurities can still be visible. Further removal of lignin and other contaminants
may cause structural damage to the fiber (Kumar and Das 2016). Fiber surface roughness
reduces the fiber-to-fiber slippage in the yarn due to better mechanical interlocking and
enhances the yarn’s mechanical characteristics (Yao and Chen 2013). Figure 6 depicts a cross-
sectional view of the extracted BV fibers. Fiber cross-sections range from circular to flat oval. An
eye-shaped lumen can be seen in a few fiber samples. The shape factor (q) of the BVFs was
calculated by implementing the below equation (Neckář and Das 2012):
(a) (b)
Figure 3. (A) Bauhinia vahlii fiber and (b) fiber length distribution of BVFs.
6 G. BAR AND K. CHAUDHARY
q ¼
p
πd
� 1 (7)
where p stands for perimeter and d symbolizes the equivalent diameter of the fiber. The value of
p and d was measured using MIPAR image analysis software. The shape factor of the BVFs is 0.1232.
In the case of circular, square, hexagonal, or triangular cross-sections, the shape factor will be 0.0,
0.1281, 0.1547, or 0.2858, respectively (Kumar and Das 2016).
Fourier transform-infrared analysis
As illustrated in Figure 7, the FTIR spectrum helps identify the functional groups present in the
BVFs. Stretching of the aromatic ring of lignin is seen at around 3650–4000 cm−1, which
validates the existence of lignin in the BVFs (Ray et al. 2020). A broad and deep absorbance
peak that appeared at 3342 cm−1 corresponds to O–H bond stretching and confirms the presence
of α–cellulose (Hyness et al. 2018; Vijay et al. 2021). Another absorbance peak observed at 2900
cm−1 is characteristic of the stretching vibration of the C–H bond, which strengthens the
presence of cellulose and hemicellulose in the BVFs (Vijay et al. 2021). A narrow peak spotted
at 1634 cm−1 is linked to the vibration of absorbed water in cellulose as well as C=O stretching
of lignin (Hyness et al. 2018). The peak that appeared at 1427 cm−1 is connected to the CH2
symmetric bending of cellulose (Chand and Fahim 2008). The peak at 1370 and 1316 cm−1 are
linked to –CH bending vibration and C–O stretching of aromatic rings of cellulose polysacchar-
ides, respectively (Zhuang et al. 2020). Peak noticed at 1204 cm−1 is assigned to –COO vibration
of the acetyl group of hemicellulose (Reddy et al. 2013). The peak noticed at 1110 cm−1 is
attributed to in-plane deformation of the aromatic C–H bond within lignin (Zhuang et al. 2020).
An intense absorbance peak observed at 1058 cm−1 and a small peak at 1036 cm−1 represented
symmetric C–O-H stretching of lignin (Maheshwaran et al. 2018). The infra-red absorption
bands at 1162 and 898 cm−1 are attributed to C–O–C stretching at β-(1–4)-glycosidic linkages of
cellulose and hemicellulose (Baskaran et al. 2018). The Fourier transform-infrared spectrum of
BVFs confirms that the fiber contains cellulose, hemicellulose, and lignin.
Figure 4. BVFs fineness distribution.
JOURNAL OF NATURAL FIBERS 7
Ta
bl
e
1.
 P
ro
pe
rt
ie
s
of
 B
VF
s
in
 c
om
pa
ris
on
 t
o
ot
he
r
na
tu
ra
l c
el
lu
lo
si
c
fib
er
s.
Fi
be
r
Fi
ne
ne
ss

(m
ic
ro
n)
D
en
si
ty
 (g
m
/
cm
3 )
St
re
ng
th

(M
Pa
)
El
on
ga
tio
n
(%
)
Cr
ys
ta
lli
ni
ty

in
de
x
Cr
ys
ta
lli
te
 S
iz
e
(n
m
)
Re
fe
re
nc
e
BV
Fs
15
.7
7
1.
47
72
-5
12
2.
4–
6.
7
56
3.
2
Cu
rr
en
t
St
ud
y
Co
tt
on
12
–3
8
1.
52
28
7–
80
0
7–
8
65
–7
0
5.
5
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; R
ed
dy
 a
nd
 Y
an
g
(2
00
8)
; E
le
ng
a
et
 a
l.
(2
00
9)
Fl
ax
40
-6
00
1.
50
34
5–
15
00
2.
7–
3.
2
70
2.
8
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; T
am
an
na
 e
t
al
. (
20
21
);
M
os
hi
 e
t
al
. (
20
19
)
Ju
te
25
–
20
0
1.
46
39
3–
80
0
1.
1–
1.
5
58
.9
3.
58
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; M
os
hi
 e
t
al
. (
20
19
);
W
an
g
et
 a
l.
(2
01
9)
H
em
p
25
–5
00
1.
47
69
0
1.
6–
2.
4
69
–8
3
–
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; R
ed
dy
 a
nd
 Y
an
g
(2
00
8)
Ra
m
ie
25
–5
0
1.
55
40
0–
93
8
1.
2–
3.
8
58
16
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; M
os
hi
 e
t a
l.
(2
01
9)
; T
am
an
na
 e
t a
l.
(2
02
1)
;
El
en
ga
 e
t
al
. (
20
09
)
Ke
na
f
12
–3
6
1.
45
25
0
1.
3–
3.
3
61
–6
9
–
Re
dd
y
an
d
Ya
ng
 (2
00
8)
, S
re
en
iv
as
, K
ris
hn
am
ur
th
y,
 a
nd
 A
rp
ith
a
(2
02
0)
Si
sa
l
25
–2
00
1.
45
46
8–
70
0
3–
7
75
–
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; M
os
hi
 e
t
al
. (
20
19
)
Al
bi
zi
a
ju
lib
ris
sin
16
2
1.
33
48
3.
40
9.
35
27
.7
7
6.
79
M
d
et
 a
l.
(2
02
2)
Ac
ac
ia
 n
ilo
tic
a
L.
–
1.
17
–
–
44
.8
2
3.
21
Ku
m
ar
 e
t
al
. (
20
22
)
Br
as
sic
a
ol
er
ac
ea
 V
ar
. I
ta
lic
58
5
1.
80
79
0
4.
3
70
.1
9
–
Ey
up
og
lu
 (2
02
1)
M
om
or
di
ca
 c
ha
ra
nt
ia
19
8
1.
34
36
.5
–
21
.4
2
–
Kh
an
 e
t
al
. (
20
22
)
Pu
rp
le
 B
au
hi
ni
a
51
1
1.
46
33
8.
6
9.
1
54
.9
8
4.
3
Ra
je
sh
ku
m
ar
 e
t
al
. (
20
21
)
Sy
m
ph
ire
m
a
in
vo
lu
cr
at
um
54
2
1.
39
39
7.
22
6.
77
28
.2
2
5.
1
Ra
ju
 e
t
al
. (
20
21
)
Sa
ns
ev
ie
ria
 r
ox
bu
rg
hi
an
a
Sc
hu
lt.

&
Sc
hu
lt.
 F
10
6
0.
95
21
3.
6
1.
12
95
.5
5
5.
25
G
op
i K
ris
hn
a,
 K
ai
la
sa
na
th
an
, a
nd
 N
ag
ar
aj
aG
an
es
h
(2
02
2)
Va
ch
el
lia
 fa
rn
es
ia
na
23
1
1.
27
33
.0
8
–
13
31
.8
9
Vi
ja
y
et
 a
l.
(2
02
2)
Zi
ng
ib
er
 O
ffi
ci
na
le
–
1.
4
22
0–
24
0
1.
1
78
.8
1
–
Ey
up
og
lu
 (2
02
2)
Be
et
ro
ot
 p
la
nt
28
4.
04
0.
52
50
.6
8
7.
72
87
3.
92
Eyup
og
lu
 a
nd
 E
yu
po
gl
u
(2
02
2)
La
ve
nd
er
 s
te
m
29
5
0.
87
22
6.
65
2.
94
–4
.6
9
79
.0
6
3.
87
Ey
up
og
lu
 a
nd
 M
er
da
n
(2
02
1a
)
Al
ce
a
ro
se
 L
.
32
0
0.
45
80
.9
6
2.
47
80
3.
89
Ey
up
og
lu
 a
nd
 M
er
da
n
(2
02
1b
)
8 G. BAR AND K. CHAUDHARY
X-ray diffraction analysis
An X-ray diffractogram of BVFs is illustrated in Figure 8. X-ray diffraction pattern of BVFs
shows two major diffraction peaks at 2θ of about 15.23° and 22.79°Correspond to (1 0 1) and (0
0 2) crystal lattice plane sequentially (Bar et al. 2021). The broad peak detected at 2θ = 15.23°
confirms the presence of hemicellulose, lignin, pectin, and amorphous cellulose (Baskaran et al.
2018). The sharp peak observed at 2θ = 22.79°Characterizes the lattice plane of cellulose I (Vijay
et al. 2021). The crystalline region of BVFs is lying in-between 2θ = 19.65° to 25.21° and 2θ =
13.17° to 17.97°. The crystallinity index of BVFs is estimated as 56%, which is very close to the
cotton fiber. The crystallinity index of BVFs is compared with other natural cellulosic fibers used
in conventional textile materials and is tabulated in Table 1. The interplanar or lattice plane
spacing in the above-mentioned diffraction peaks is computed using Bragg’s equation and
Figure 5. Longitudinal view of BVFs extracted at 1500X magnification.
(b) (a) Lumen
Figure 6. Cross-sectional view of BVFs (a) at 2000X magnification (b) at 5000X magnification.
JOURNAL OF NATURAL FIBERS 9
determined to be 0.58 and 0.39 nm sequentially. The crystal lattice planes are very close and
tightly packed at 2θ of 22.79°Compared to 15.23° (Kumar and Das 2016). The crystallite sizes of
the BVFs determined against (1 0 1) and (0 0 2) crystal lattice planes are 3.85 and 2.56 nm,
respectively. The average crystallite size of BVFs is 3.2 nm, smaller than the Indian cotton fiber
of 5.5 nm, cornstalk fiber of 3.8 nm, ramie of 16 nm (Elenga et al. 2009), and jute of 3.58 nm
(Wang et al. 2019). However, it is slightly larger than that of flax 2.8 nm (Tamanna et al. 2021).
The average crystallite size of BVFs is close to the other conventional natural cellulosic fibers
used to produce yarns and fabrics. Fibers having equivalent crystallinity and lower crystallite size
increase the chemical reactivity as well as moisture absorption capacity due to its larger total
surface area compared to bigger crystallite sizes (Elenga et al. 2009).
Figure 7. FTIR spectrum of BVFs.
Figure 8. X-ray diffractogram of BVFs.
10 G. BAR AND K. CHAUDHARY
Chemical analysis
The physical properties of any fiber depend on its chemical constituents. Further, the chemical
composition of lignocellulosic fiber is affected not only by the kind of plant but also on the
geographical location and climatic condition where the plant grows, the plant’s age, and the fiber
extraction method (Baskaran et al. 2018). Bauhinia vahlii fiber was extracted with 15% NaOH solution
containing 75.8% holocellulose, of which 65.2% was α-cellulose and 10.6% hemicellulose. The α-
cellulose content of BVFs is very much comparable with other lignocellulosic fibers, whereas hemi-
cellulose content is lower than that of flax, jute, hemp, and sisal. Bauhinia vahlii fiber also contained
13.7% acid insoluble klason lignin, which is also lower than the flax, jute, and kenaf fiber, as concluded
in Table 2. Bauhinia vahlii fiber also contained 1.8% pectin. The moisture content of the BVFs is
measured as 10.5%, which is higher than the cotton fiber and at par with other natural cellulosic fibers,
also tabulated in Table 2. The lower crystallinity and crystallite size of BVFs enhance the moisture
absorption in the fiber (Elenga et al. 2009).
Tensile strength
The tensile property of fibers mainly depends on their chemical components and their percentage. For
natural cellulosic fibers, cellulose microfibrils act as a load-bearing component and give structural
integrity to the fiber. The strength of a fiber depends on its microfibril angle as well as its orientation in
the cell wall (Petroudy 2017). The microfibril angle (α) is derived by applying the global deformation
(ε) equation (Maheshwaran et al. 2018).
ε ¼ ln 1þ
ΔL
L0
� �
¼ � ln cosαð Þ (8)
L0 is the gauge length in mm, and ΔL is the breaking elongation in mm. The microfibril angle of BVFs
varies from 12.43° to 20.41°, which is higher than other natural cellulosic fibers like jute (8.1°), ramie
(8°), flax (5°), hemp (6.2°), and very similar to sisal (10°–25°), cotton (14.6°–23.8°) (Maheshwaran et al.
2018; Petroudy 2017). The fiber sample mounted for testing and the tensile strength–elongation curve
of BVFs is shown in Figure 9. It was observed from the tensile strength-elongation graph that the curve
is slightly concave to the elongation axis, like the other natural cellulosic fibers. The tensile strength
and elongation have a linear relationship (Eyupoglu 2022). The average breaking strength of BVFs is
187 Mpa. The tensile strength of BVFs is a little less compared to other natural cellulosic fibers due to
their very fine mesh structure and higher microfibril angle. The higher microfibril angle also indicates
that the BVFs is less stiff than the jute and flax fiber (Petroudy 2017). The breaking elongation of BVFs
varies from 2.4% to 6.7%, with an average breaking elongation of 4.4%, which is higher than the flax,
jute, hemp, sisal, and kenaf fiber and lower than cotton fiber. Table 1 compares tensile strength and
breaking elongation of BVFs with other fibers.
Thermogravimetric analysis
Thermogravimetric and derivative thermogravimetric curves were derived from the thermal study of BVFs
from ambient temperature to 750°C, as illustrated in Figure 10. Thermogravimetric analysis curve of BVFs
exhibits multiple phases of degradation with an increase in temperature. In the first phase of degradation,
two small endothermic peaks are seen in the DTG curve at 59°C and 151°C, which is attributed to the
evaporation of moisture and elimination of structurally bound water molecules in the fiber (Alwani et al.
2014; Legrand et al. 2020). Till 159°C, 9.83% weight loss is observed. From 159°C to 233.4°C, the BVFs is
thermally stable, having a minimal weight loss of 0.55%. Textile materials manufactured from BVFs can be
processed or ironed at this temperature. In the second phase of degradation, which starts from 233.4°C,
weight loss of 62.05% is noticed, which refers to the disintegration of hemicellulose, glycosidic linkages of
cellulose, cellulose I, and α-cellulose (Belouadah, Ati, and Rokbi 2015). A deep endothermic peak at 368°C
JOURNAL OF NATURAL FIBERS 11
Ta
bl
e
2.
 C
he
m
ic
al
 c
om
po
si
tio
n
of
 B
VF
s
in
 c
om
pa
ris
on
 t
o
ot
he
r
na
tu
ra
l c
el
lu
lo
si
c
fib
er
s.
Fi
be
r
Ce
llu
lo
se

(w
t%
)
H
em
i
ce
llu
lo
se

(w
t%
)
Li
gn
in

(w
t%
)
Pe
ct
in

(w
t%
)
W
ax

(w
t%
)
As
h

(w
t%
)
M
oi
st
ur
e
co
nt
en
t
(%
)
Re
fe
re
nc
es
BV
Fs
65
.2
10
.6
13
.7
1.
8
–
–
10
.5
Cu
rr
en
t
St
ud
y
Co
tt
on
82
.7
5.
7
–
–
0.
6
–
7.
85
–8
.5
Sa
th
is
hk
um
ar
 e
t
al
. (
20
13
);
Ta
m
an
na
 e
t
al
. (
20
21
)
Fl
ax
60
–8
1
18
.6
–2
0.
6
14
–1
9
2.
3
1.
7
–
10
.0
M
ew
ol
i e
t
al
. (
20
20
);
Ta
m
an
na
 e
t
al
. (
20
21
)
Ju
te
45
–8
4
12
–2
1
13
–2
6
0.
2
–
0.
5–
2
12
.6
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; M
ew
ol
i e
t
al
. (
20
20
);
Am
ut
ha
 a
nd

Se
nt
hi
lk
um
ar
 (2
02
1)
H
em
p
70
–7
4
17
.9
–2
2.
4
3.
5–

5.
7
0.
9
0.
8
0.
8
10
.1
3
M
ew
ol
i e
t
al
. (
20
20
).
St
ev
ul
ov
a
et
 a
l.
(2
01
5)
Ra
m
ie
68
.6
–9
1
5–
16
.7
0.
6–

0.
7
1.
9
–
–
8.
0
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; T
am
an
na
 e
t
al
. (
20
21
)
Ke
na
f
31
–6
3.
5
17
.6
–2
1.
5
15
–1
9
2
–
2–
5
6–
12
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; M
ew
ol
i e
t
al. (
20
20
);
Ta
m
an
na
 e
t
al
.
(2
02
1)
Si
sa
l
47
–7
8
10
–2
4
7–
11
10
–
0.
6–
1
10
.2
2
Ch
an
d
an
d
Fa
hi
m
 (2
00
8)
; T
am
an
na
 e
t
al
. (
20
21
)
Al
bi
zi
a
ju
lib
ris
sin
55
.8
3
10
.7
4
16
.0
3
–
0.
53
10
.8
4
8.
44
M
d
et
 a
l.
(2
02
2)
Ac
ac
ia
 n
ilo
tic
a
L.
56
.4
6
14
.1
4
8.
33
–
0.
85
4.
93
-
Ku
m
ar
 e
t
al
. (
20
22
)
Br
as
sic
a
ol
er
ac
ea
 V
ar
. I
ta
lic
47
.8
–
13
.4
–
–
–
–
Ey
up
og
lu
 (2
02
1)
M
om
or
di
ca
 c
ha
ra
nt
ia
61
.2
7.
3
14
.3
2
–
1.
1
2.
24
6.
3
Kh
an
 e
t
al
. (
20
22
)
Pu
rp
le
 B
au
hi
ni
a
60
.5
4
9.
17
16
.2
7
–
1.
28
6.
24
10
.5
4
Ra
je
sh
ku
m
ar
 e
t
al
. (
20
21
)
Sy
m
ph
ire
m
a
in
vo
lu
cr
at
um
57
.3
2
12
.4
7
13
.8
5
–
0.
56
–
9.
11
Ra
ju
 e
t
al
. (
20
21
)
Sa
ns
ev
ie
ria
 r
ox
bu
rg
hi
an
a
Sc
hu
lt.

&
Sc
hu
lt.
 F
78
.6
3
2.
01
9.
86
-
0.
16
1.
49
7.
85
G
op
i K
ris
hn
a,
 K
ai
la
sa
na
th
an
, a
nd
 N
ag
ar
aj
aG
an
es
h
(2
02
2)
Va
ch
el
lia
 fa
rn
es
ia
na
38
.3
12
.1
9.
2
–
3.
4
6.
21
11
Vi
ja
y
et
 a
l.
(2
02
2)
Zi
ng
ib
er
 O
ffi
ci
na
le
70
.0
5
26
.4
5
3.
5
–
–
–
–
Ey
up
og
lu
 (2
02
2)
W
as
hi
ng
to
ni
a
le
af
 s
ta
lk
32
.1
9
19
.3
4
10
.0
4
–
–
8.
1
–
Ja
w
ai
d
et
 a
l.
(2
02
1)
12 G. BAR AND K. CHAUDHARY
is attributed to the higher decomposition rate. The decomposition rate is reduced in the third phase of
degradation, which ranges from 385°C to 696°C with 11.92% weight loss, which is associated with the
decomposition of residual cellulose, lignin, and aromatics contained in BVFs (Legrand et al. 2020). The
endothermic peak observed at 491°C links to maximal lignin degradation and thermal depolymerization of
wax (Maheshwaran et al. 2018). Lignin decomposes slowly compared to cellulose and hemicellulose over
a broad range of temperatures owing to several functional groups having varied thermal stabilities present
in the fiber (Brebu and Vasile 2010). At 740°C, char content is 15.65%. The minimum energy required for
the degradation of the fiber at a certain temperature is known as kinetic activation energy (Ea). The Ea of
BVFs is 96.18 KJ/mol, as calculated from the Broido’s plot shown in Figure 10. The Ea of BVFs is within the
range that of the other natural fibers (60–170 KJ/mol) (Md et al. 2022).
Conclusion
Successful extraction of BVFs has been accomplished from the BV plant bark using 15% NaOH solution at
95°C. The morphological study reveals that the fiber surface has natural roughness, and the cross-sectional
view varies from circular to flat oval. The fineness and the density of the BVFs are very close to the cotton
fiber, and the average fiber length is slightly shorter than the cotton fiber. The FTIR and the chemical
analysis have confirmed that extracted BVFs are rich in cellulose content. X-ray analysis of BVFs is exposed
(a) (b)
Figure 10. (a) Thermogravimetric and derivative thermogravimetric curves, and (b) Broido’s plot of BVFs.
(a) (b)
Figure 9. (a) BVFs mounted sample and (b) tensile strength elongation curve of BVFs.
JOURNAL OF NATURAL FIBERS 13
that it has 56% crystallinity, and the crystallite size of BVFs is smaller than the cotton fiber, which enhances
its moisture absorption capacity as well as its reactivity. The thermogravimetric analysis proclaimed that
BVFs is thermostable up to 233.4°C, and physical and chemical processing of this fiber can be done up to
this temperature. The average tensile strength of the BVFs is 187 Mpa with 4.4% average breaking
elongation. Findings of all the analyzes suggest that the extracted fiber can be used to convert them into
yarn by blending with some short-staple cellulosic fiber-like cotton with a lower blend ratio keeping tensile
strength into consideration.
Highlights
● Textile-grade novel Bauhinia Vahlii fiber (BVFs) were extracted by treating the Bauhinia Vahlii plant bark with 15%
(w/w) sodium hydroxide solution at 95°C for 2 h with a 1:40 material to liquor ratio, followed by manual extraction of
the fiber.
● The average fineness and the density of the BVFs are 15.77 microns and 1.47 gm/cm3, respectively. The mean fiber
length of BVFs is 20.05 mm. BVFs contain 65.2% cellulose, 10.6% hemicellulose, 13.7% lignin, and 10.5% moisture.
The average tensile strength of the BVFs is 187 Mpa with a 4.4% average breaking elongation.
● BVFs have 56% crystallinity. The average crystallite size is 2 nm, smaller than the cotton fiber’s, enhancing moisture
absorption capacity and reactivity.
● BVFs are thermally stable up to 233.4°C.
● Findings of all the analyzes suggest that the extracted fiber can be used to convert them into yarn by blending with
some short-staple cellulosic fiber like cotton with a lower blend ratio keeping the fiber length and tensile strength into
consideration. Introduction
Acknowledgment
The authors want to thank the CRF, IIT Delhi, for extending their support in material testing.
Disclosure statement
No potential conflict of interest was reported by the authors.
Funding
The authors received no financial assistance for their research, authorship, or article publication.
ORCID
Goutam Bar http://orcid.org/0000-0001-7620-4307
Ethical approval
This article does not contain any studies with human or animal subjects. Hence, ethical approval is not applicable.
References
Alwani, M. S. Alwani, H. P. S. A. Khalil, O. Sulaiman, M. N. Islam, and R. Dungani. 2014. An approach to using
agricultural waste fibres in biocomposites application: Thermogravimetric analysis and activation energy study.
BioResources 9 (1):218–30. doi:10.15376/biores.9.1.218-230.
Amutha, V., and B. Senthilkumar. 2021. Physical, chemical, thermal, and surface morphological properties of the bark
fiber extracted from Acacia concinna plant. Journal of Natural Fibers 18 (11):1661–74. doi:10.1080/15440478.2019.
1697986.
Bar, G., and M. Bar. 2020. Dyeing and flame-retardant finishing of silk fabric: An ecofriendly approach. SN Applied
Sciences 2 (3):3. doi:10.1007/s42452-020-2114-8.
14 G. BAR AND K. CHAUDHARY
https://doi.org/10.15376/biores.9.1.218-230
https://doi.org/10.1080/15440478.2019.1697986
https://doi.org/10.1080/15440478.2019.1697986
https://doi.org/10.1007/s42452-020-2114-8
Bar, M., H. Belay, A. Ramasamy, A. Das, and P. Ouagne. 2021. Refining of banana fiber for load bearing application
through emulsion treatment and its comparison with other traditional methods. Journal of Natural Fibers 1–18.
doi:10.1080/15440478.2021.1902901.
Baskaran, P. G., M. Kathiresan, P. Senthamaraikannan, and S. S. Saravanakumar. 2018. Characterization of new natural
cellulosic fibre from the bark of Dichrostachys cinerea. Journal of Natural Fibers 15 (1):62–68. doi:10.1080/15440478.
2017.1304314.
Belouadah, Z., A. Ati, and M. Rokbi. 2015. Characterization of new natural cellulosic fiber from Lygeum Spartum L.
Carbohydrate Polymers 134 (10):429–37. doi:10.1016/j.carbpol.2015.08.024.
Brebu, M., and C. Vasile. 2010. Thermal degradation of lignin – a review. Cellulose Chemistry and Technology
44 (9):353–63.
Chand, N., and M. Fahim. ed., 2008. Natural fibers and their composites. in Tribology of Natural Fiber and Polymer
Composites 1–58. Woodhead Publishing. doi:10.1533/9781845695057.1.
Chauhan, R., and S. Saklani. 2013. Bauhinia Vahlii: Plant to be explored. International Research Journal of Pharmacy
4 (8):5–9. doi:10.7897/2230-8407.04802.
Elenga, R. G., G. F. Dirras, J. G. Maniongui, P. Djemia, and M. P. Biget. 2009. On the microstructure and physical
properties of untreated raffia textilis fiber. Composites Part A Applied Science and Manufacturing 40 (4):418–22.
doi:10.1016/j.compositesa.2009.01.001.
Eyupoglu, S. 2021. Characterization of a Novel Cellulosic Fiber from Brassica oleracea Var. Italic Stem. Journal of
Natural Fibers 1–11. doi:10.1080/15440478.2021.1950098.
Eyupoglu, S. 2022. Characterizationof New Cellulosic Fibers Obtained from Zingiber Officinale. Journal of Natural
Fibers 19 (4):1287–96. doi:10.1080/15440478.2020.1764452.
Eyupoglu, S., and C. Eyupoglu. 2022. Investigation of a New Natural Cellulosic Fiber Extracted from Beetroot Plant.
Journal of Natural Fibers 1–12. doi:10.1080/15440478.2022.2108956.
Eyupoglu, S., and N. Merdan. 2021a. Physicochemical Properties of New Plant Based Fiber from Lavender Stem. Journal
of Natural Fibers 1–11. doi:10.1080/15440478.2021.1982816.
Eyupoglu, S., and N. Merdan. 2021b. Investigation of the characteristic and sound absorption properties of a new
cellulose-based fiber from Alcea rose L. plant. Journal of Natural Fibers 1–12. doi:10.1080/15440478.2021.1993481.
Gopi Krishna, M., C. Kailasanathan, and B. NagarajaGanesh. 2022. Physico-chemical and morphological characteriza-
tion of cellulose fibers extracted from Sansevieria roxburghiana Schult. & Schult. F leaves. Journal of Natural Fibers
19 (9):3300–16. doi:10.1080/15440478.2020.1843102.
Hyness, N. R. J., N. J. Vignesh, P. Senthamaraikannan, S. S. Saravanakumar, and M. R. Sanjay. 2018. Characterization of
new natural cellulosic fiber from Heteropogon contortus plant. Journal of Natural Fibers 15 (1):146–53. doi:10.1080/
15440478.2017.1321516.
Jawaid, M., L. K. Kian, H. Fouad, N. Saba, O. Y. Alothman, and M. Hashem. 2021. New cellulosic fibers from
washingtonia tree agro-wastes: Structural, morphological, and thermal properties. Journal of Natural Fibers 1–11.
doi:10.1080/15440478.2021.1875374.
John, M., and S. Thomas. 2008. Biofibres and biocomposites. Carbohydrate Polymers 71 (3):343–64. doi:10.1016/j.
carbpol.2007.05.040.
Kale, R. D., T. G. Alemayehu, and V. G. Gorade. 2020. Extraction and characterization of lignocellulosic fibers from
Girardinia bullosa (steudel) wedd. (Ethiopian kusha plant). Journal of Natural Fibers 17 (6):906–20. doi:10.1080/
15440478.2018.1539940.
Khan, A., V. Raghunathan, D. L. Singaravelu, M. R. Sanjay, S. Siengchin, M. Jawaid, K. A. Alamry, and A. M. Asiri. 2022.
Extraction and characterization of cellulose fibers from the stem of momordica charantia. Journal of Natural Fibers
19 (6):2232–42. doi:10.1080/15440478.2020.1807442.
Kumar, N., and D. Das. 2016. Alkali treatment on nettle fibers. The Journal of the Textile Institute 108 (8):1461–67.
doi:10.1080/00405000.2016.1257346.
Kumar, S., V. K. Patel, K. K. S. Mer, B. Gangil, T. Singh, and G. Fekete. 2021. Himalayan natural fiber-reinforced epoxy
composites: Effect of Grewia optiva/Bauhinia vahlii fibers on physico-mechanical and dry sliding wear behavior.
Journal of Natural Fibers 18 (2):192–202. doi:10.1080/15440478.2019.1612814.
Kumar, R., S. Sivaganesan, P. Senthamaraikannan, S. S. Saravanakumar, A. Khan, S. A. A. Daniel, and L. Loganathan.
2022. Characterization of new cellulosic fiber from the bark of Acacia nilotica L. plant. Journal of Natural Fibers
19 (1):199–208. doi:10.1080/15440478.2020.1738305.
Legrand, N. B. R., M. Lucien, O. Pierre, B. E. Fabien, N. P. Marcel, and A. A. Jean. 2020. Physico-chemical and thermal
characterization of a lignocellulosic fiber, extracted from the bast of cola lepidota stem. Journal of Minerals and
Materials Characterization and Engineering 8 (5):377–92. doi:10.4236/jmmce.2020.85024.
Ling, Z. Ling, T. Wang, M. Makarem, M. Santiago Cintrón, H. N. Cheng, X. Kang, M. Bacher, A. Potthast, T. Rosenau,
et al. 2019. Effects of ball milling on the structure of cotton cellulose. Cellulose. 26(1):305–28. doi:10.1007/s10570-018-
02230-x.
Maheshwaran, M. V., N. R. J. Hyness, P. Senthamaraikannan, S. S. Saravanakumar, and M. R. Sanjay. 2018.
Characterization of natural cellulosic fiber from epipremnum aureum stem. Journal of Natural Fibers
15 (6):789–98. doi:10.1080/15440478.2017.1364205.
JOURNAL OF NATURAL FIBERS 15
https://doi.org/10.1080/15440478.2021.1902901
https://doi.org/10.1080/15440478.2017.1304314
https://doi.org/10.1080/15440478.2017.1304314
https://doi.org/10.1016/j.carbpol.2015.08.024
https://doi.org/10.1533/9781845695057.1
https://doi.org/10.7897/2230-8407.04802
https://doi.org/10.1016/j.compositesa.2009.01.001
https://doi.org/10.1080/15440478.2021.1950098
https://doi.org/10.1080/15440478.2020.1764452
https://doi.org/10.1080/15440478.2022.2108956
https://doi.org/10.1080/15440478.2021.1982816
https://doi.org/10.1080/15440478.2021.1993481
https://doi.org/10.1080/15440478.2020.1843102
https://doi.org/10.1080/15440478.2017.1321516
https://doi.org/10.1080/15440478.2017.1321516
https://doi.org/10.1080/15440478.2021.1875374
https://doi.org/10.1016/j.carbpol.2007.05.040
https://doi.org/10.1016/j.carbpol.2007.05.040
https://doi.org/10.1080/15440478.2018.1539940
https://doi.org/10.1080/15440478.2018.1539940
https://doi.org/10.1080/15440478.2020.1807442
https://doi.org/10.1080/00405000.2016.1257346
https://doi.org/10.1080/15440478.2019.1612814
https://doi.org/10.1080/15440478.2020.1738305
https://doi.org/10.4236/jmmce.2020.85024
https://doi.org/10.1007/s10570-018-02230-x
https://doi.org/10.1007/s10570-018-02230-x
https://doi.org/10.1080/15440478.2017.1364205
Md, J. S., S. Madhu, K. Chakravarthy, and J. S. N. Raju. 2022. “Characterization of natural cellulose fibers from the stem
of Albizia Julibrissin as reinforcement for polymer composites. Journal of Natural Fibers 19 (6):2204–17. doi:10.1080/
15440478.2020.1807440.
Mewoli, A. E., C. Segovia, F. B. Ebanda, A. Ateba, P. M. A. Noah, B. Ndiwe, and A. E. Njom. 2020. Physical-chemical and
mechanical characterization of the bast fibers of Triumfetta cordifolia A. rich. from the equatorial region of cameroon.
Journal of Minerals and Materials Characterization and Engineering 8 (4):163–76. doi:10.4236/jmmce.2020.84011.
Moshi, A. A. M., D. Ravindran, S. R. S. Bharathi, V. Suganthan, and G. K. S. Singh. 2019. “Characterization of new natural
cellulosic fibers – a comprehensive review”. IOP Conference Series: Materials Science and Engineering, Kanchipuram,
India, 574:1–11 doi:10.1088/1757-899X/574/1/012013.
Neckář, B., and D. Das, ed. 2012. Theory of structure and mechanics of fibrous assemblies: Basic properties of
single fibers and fibrous assemblies 1–28. New Delhi: Woodhead Publishing India Pvt. Ltd. doi:10.1201/
9780367805548.
Olesen, P. O., and D. V. Plackett. 1999. Perspectives on the performance of natural plant fibres. The Natural Fibres
Performance Forum, Copenhagen, Denmark, May 27-28.
Petroudy, S. R. D. 2017. Physical and mechanical properties of natural fibers. In Book advanced high strength natural
fibre composites in construction, ed. M. Fan and F. Fu, 59–83. Woodhead Publishing. doi: 10.1016/B978-0-08-
100411-1.00003-0.
Rajeshkumar, G., G. L. Devnani, J. P. Maran, M. R. Sanjay, S. Siengchin, N. A. Al-Dhabi, and K. Ponmurugan. 2021.
Characterization of novel natural cellulosic fibers from purple bauhinia for potential reinforcement in polymer
composites. Cellulose 28 (9):5373–85. doi:10.1007/s10570-021-03919-2.
Raju, J. S. N., M. V. Depoures, J. Shariff, and S. Chakravarthy. 2021. Characterization of natural cellulosic fibers from
stem of symphirema involucratum plant. Journal of Natural Fibers 1–16. doi:10.1080/15440478.2021.1875376.
Ramasamy, R., and R. B. Subramanian. 2021. Synthetic textile and microfiber pollution: A review on mitigation
strategies. Environmental Science and Pollution Research 28 (31):41596–611. doi:10.1007/s11356-021-14763-z.
Ray, R., S. N. Das, A. Mohapatra, and H. C. Das. 2020. Comprehensive characterization of a novel natural Bauhinia
Vahlii stem fiber. Polymer Composites 41 (9):3807–16. doi:10.1002/pc.25678.
Reddy, K. O., K. R. N. Reddy, J. Zhang, J. Zhang, and A. V. Rajulu. 2013. Effect of alkali treatment on the properties of
Century fiber. Journal of Natural Fibers 10 (3):282–96. doi:10.1080/15440478.2013.800812.
Reddy, N., and Y. Yang. 2008. Characterizing natural cellulose fibers from velvet leaf (Abutilon theophrasti) stems.
Bioresource Technology 99 (7):2449–54. doi:10.1016/j.biortech.2007.04.065.
Sathishkumar, T. P., P.Navaneethakrishnan, S. Shankar, and R. Rajasekara. 2013. Characterization of new cellulose
Sansevieria ehrenbergii fibers for polymer composites. Composite Interfaces 20 (8):575–93. doi:10.1080/15685543.
2013.816652.
Sengupta, A. B., S. K. Mazumdar, and N. G. Macmillan. 1958. Isolation of jute holocellulose by the action of sodium
chlorite. Indian Journal of Applied Chemistry 21:105–10.
Sreenivas, H. T., N. Krishnamurthy, and G. R. Arpitha. 2020. A comprehensive review on light weight kenaf fiber for
automobiles. International Journal of Lightweight Materials and Manufacture 3 (4):328–37. doi:10.1016/j.ijlmm.2020.
05.003.
Stalin, B., and R. Ramkumar. 2015. Mechanical properties of Bauhinia racemosa fiber reinforced with polymer
composites. International Journal of Applied Engineering Research 10 (51):701–05.
Stevulova, N., J. Cigasova, P. Purcz, I. Schwarzova, F. Kacik, and A. Geffert. 2015. Water absorption behavior of hemp
hurds composites. Materials 8 (5):2243–57. doi:10.3390/ma8052243.
Tamanna, T. A., S. A. Belal, M. A. H. Shibly, and A. N. Khan. 2021. Characterization of a new natural fiber extracted
from Corypha taliera fruit. Scientific reports 11 (1):1–12. doi:10.1038/s41598-021-87128-8.
Vijay, R., J. D. J. Dhilip, S. Gowtham, S. Harikrishnan, B. Chandru, M. Amarnath, and A. Khan. 2022. Characterization
of natural cellulose fiber from the barks of vachellia farnesiana. Journal of Natural Fibers 19 (4):1343–52. doi:10.1080/
15440478.2020.1764457.
Vijay, R., D. L. Singaravelu, A. Vinod, M. R. Sanjay, and S. Siengchin. 2021. Characterization of alkali-treated and
untreated natural fibers from the stem of Parthenium hysterophorus. Journal of Natural Fibers 18 (1):80–90. doi:10.
1080/15440478.2019.1612308.
Wang, L., X. Liu, X. Zheng, and Y. Tian. 2015. Extraction of pectin from flax fiber by chemical means. International
Journal of Clothing Science and Technology 27 (3):390–96. doi:10.1108/IJCST-03-2014-0037.
Wang, L., and X. Wang. 2009. Effect of structure–property relationships on fatigue failure in natural fibres. In Fatigue
failure of textile fibres, ed. M. Miraftab, 95–132. Woodhead Publishing. doi: 10.1533/9781845695729.2.95.
Wang, X., L. Wang, W. Ji, Q. Hao, G. Zhang, and Q. Meng. 2019. Characterization of KH-560-modified jute fabric/epoxy
laminated composites: Surface structure, and thermal and mechanical properties. Polymers 11 (5):769. doi:10.3390/
polym11050769.
Yao, Y., and S. Chen. 2013. The effects of fiber’s surface roughness on the mechanical properties of fiber-reinforced
polymer composites. Journal of Composite Materials 47 (23):2909–23. doi:10.1177/0021998312459871.
Zhuang, J., M. Li, Y. Pu, A. J. Ragauskas, and C. G. Yoo. 2020. Observation of potential contaminants in processed
biomass using Fourier transform infrared spectroscopy. Applied Sciences 10 (12):1–13. doi:10.3390/app10124345.
16 G. BAR AND K. CHAUDHARY
https://doi.org/10.1080/15440478.2020.1807440
https://doi.org/10.1080/15440478.2020.1807440
https://doi.org/10.4236/jmmce.2020.84011
https://doi.org/10.1088/1757-899X/574/1/012013
https://doi.org/10.1201/9780367805548
https://doi.org/10.1201/9780367805548
https://doi.org/10.1016/B978-0-08-100411-1.00003-0
https://doi.org/10.1016/B978-0-08-100411-1.00003-0
https://doi.org/10.1007/s10570-021-03919-2
https://doi.org/10.1080/15440478.2021.1875376
https://doi.org/10.1007/s11356-021-14763-z
https://doi.org/10.1002/pc.25678
https://doi.org/10.1080/15440478.2013.800812
https://doi.org/10.1016/j.biortech.2007.04.065
https://doi.org/10.1080/15685543.2013.816652
https://doi.org/10.1080/15685543.2013.816652
https://doi.org/10.1016/j.ijlmm.2020.05.003
https://doi.org/10.1016/j.ijlmm.2020.05.003
https://doi.org/10.3390/ma8052243
https://doi.org/10.1038/s41598-021-87128-8
https://doi.org/10.1080/15440478.2020.1764457
https://doi.org/10.1080/15440478.2020.1764457
https://doi.org/10.1080/15440478.2019.1612308
https://doi.org/10.1080/15440478.2019.1612308
https://doi.org/10.1108/IJCST-03-2014-0037
https://doi.org/10.1533/9781845695729.2.95
https://doi.org/10.3390/polym11050769
https://doi.org/10.3390/polym11050769
https://doi.org/10.1177/0021998312459871
https://doi.org/10.3390/app10124345
	Abstract
	摘要
	Introduction
	Material and methods
	Materials
	Fiber extraction process
	Physical property analysis
	Morphological characterization
	Fourier transform-infrared analysis
	X-ray diffraction analysis
	Chemical analysis
	Mechanical characterization
	Thermogravimetric analysis
	Results and discussion
	Physical property analysis
	Morphological characteristics
	Fourier transform-infrared analysis
	X-ray diffraction analysis
	Chemical analysis
	Tensile strength
	Thermogravimetric analysis
	Conclusion
	Highlights
	Acknowledgment
	Disclosure statement
	Funding
	ORCID
	Ethical approval
	References
