Slope Stability Analysis: Slide2
Module 2A
Objectives
1. Features of :
• Modeler (Model building)
• Engine
• Interpreter (Interpretation of results)
2. Example 1: Setting up a model
3. Specialized Slide2 Features
1. Thrust Line
2. Soil Profile Modeling
3. NEW: Integration with RSLog
1. Example 2: Import from RSLog
4. Multi-Scenario Modeling
Model
ComputeInterpret
Modeler, Engine, & Interpreter
Modeler: Model Creation
Geometry tools
• External boundary
• Material boundary
• Tension crack
• Water surface
• Weak layer
• Anisotropic surface
• Damage Region
• Soil Profile Boundary
Entity modification
• Move, delete, stretch
Loadings
• Distributed load
• Line load
• Seismic load
Support systems
• Single support
• Pattern support
Modeler: Search Surfaces & Properties
Surfaces
• Circular
• Non-circular
• Slope limits
• Edit
Properties
• Materials
• 20 material strength models
• Supports
• 10 support models
• Tension Crack
Modeler: Project Settings: General
Project settings
• General
• Units
• Failure direction
• Output data
Modeler: Project Settings: Methods
Project settings
• Methods
• 11 stability analysis methods
• Analysis convergence options
Modeler: Project Settings: Groundwater
Project settings
• Groundwater
• 6 Methods
• Finite element analysis
• Excess Pore Pressure
• Rapid Drawdown methods
Modeler: Project Settings: Statistics
Project settings
• Statistics
• Probabilistic analysis
• Spatial variability
• Sensitivity analysis
• Analysis type
• Global minimum
• Overall slope
Modeler: Seepage & Statistics
FE groundwater analysis options
• Mesh
• Boundary conditions
• Discharge sections
• Hydraulic Material Properties
• 5 conductivity models
Statistical analysis options
• Materials
• Supports
• Loads
• Seismic loads
• Water tables
• Tension cracks
Compute Engine
• Slope stability analysis engine
• Limit equilibrium methods
• Groundwater engine
• Finite element method
Interpreter: Viewing and analyzing results
Filtering options for factor of safety
• Method
• Global
• Surfaces
Queries
• Graph queries
• Information on slices
Support
• View support forces
• View back analysis surface (supports)
Groundwater
• Computed quantities
• Queries
• Flow lines
• Flow vectors
Interpreter: Viewing and analyzing results
Statistical analysis
• Cumulative plots
• Histogram plots
• Sensitivity plots
• Data export
Interpreter: Data Interpretation Tools
Visualization tools that facilitate results interpretation
• Contour and line plots
• Coloring of critical slip surfaces
• Viewing of multiple plots
Interpreter: Reporting Tools
Drawings tools
• Static texts
• Material Properties Table
• Method Results Table
• Drawing tools
• Dimensioning tools
Advanced printing features
• Customized report footer with your
company logo
• Report Generator
Example 1
Example 1
Basic modelling steps
• Project Settings
• Create slope geometry using import
DXF
• Create material boundaries using
import DXF
• Geometry Cleanup
• Import and assign material properties
• Surface Option (Circular surface)
• Compute and Interpret
• Water Surface
• Line of Thrust
• Tension Crack
Thrust Line
Thrust Line
• Represents location of (resultant) interslice forces
• Computed by summing moments of all forces acting on individual slice about
centre of slice base
• Two schools of thought:
• Solution most reasonable when line of thrust is within sliding mass to prevent
tension (Sharma et al, XSTABL)
• Nothing wrong with tension (Duncan, Bromhead)
With tension crack Without tension crack
Thrust Line
Eliminating Tension
Two Methods:
• Tension crack defined in model.
• Adjustment of Mohr failure envelope so that there is no shear strength when
the normal stress becomes negative.
Tension Crack
• Tension crack terminates the slip surface at the edge of a slice at an
appropriate depth below the ground surface
• Depth can be estimated using:
𝑑𝑐𝑟𝑎𝑐𝑘 =
2𝑐𝑑
𝛾 tan 45 − 𝜙𝑑/2
Tension Crack
• Should not extend beyond the depth of tension
• If the crack depth is overestimated, compressive forces will be eliminated and
the factor of safety will be overestimated
• Often, a tension crack has a minor effect on the computed factor of safety
• Introducing a tension crack eliminates numerical instability issues and
negative stresses
Determining Tension Crack Depth
Perform a series of analyses, varying the depth of the crack
• FS will first decrease as the depth of the crack is increased and tension is
eliminated, then increases as the depth increases further and compressive
stresses are eliminated as well
• Cannot be used if the tension crack is filled with water because:
• due to the water pressure, the force on the wall of the tension crack is always
compressive, and the deeper the crack, the lower the factor of safety.
Slope Stability Analysis – Example II
• Basic modelling steps
• Create slope geometry using
Image Importer
• Import/define material properties
• Define failure surfaces
• Circular surface
• Compute and Interpret
Import Drawing as Image
• Select Pseudo transparent to be able to see the image overlaid on top of geometry and
select Finish
Assign Material Properties
• Properties > Assign Properties
• Select the material in the Assign Materials
dialog then select each region to assign the
property
Soil Profile Modeling
Introduction to Soil Profile
• An extension of the geometry modeling capabilities of Slide2
• Allows you to define a master profile of your material boundaries (e.g.
geological or soil profile) and ground surface.
• The profile is used as a base template, over which you can use the regular
boundary options (e.g. Add External, Add Material) to superimpose different
slope geometries (e.g. cut back a slope).
• Useful for models with relatively complex material layering, over which you
would like to define several different slope excavation scenarios
• Helpful to use a Soil Profile with Multi Scenario modeling
Soil Profile and Geometry Workflow Tabs
• Define Profile by activating the
option in Project Settings
• Import Material and Top Surface
using DXF imports
• Define and try different slope
geometries by using Window,
Polyline and DXF import options
for adding External Boundary
• Change slope angle or
• Slope angle wizard
Soil Profile from Borehole Data
• Define boreholes in Borehole Editor
(Profile > Borehole Editor)
• Add borehole(s)
• Specify x- location and top elevation
• Specify material layers and layer
thicknesses
• Specify borehole interpolation settings
• Create slope geometry by importing
DXF files
Multi-Scenario Modeling
Multi Scenario Model
• Allows the user to create and
analyze multiple variations in one
file
• Users can create an unlimited
number of variations to analyze
Project Settings Window to select Multiple Scenarios Option
Multi Scenario Analyses allow the user to compare multiple scenarios at once
Groups and Scenarios
• Group – a set of scenarios with the
same external and material
boundaries
• Master Scenario – any edits made
to this scenario affect all scenarios
in a group
• Scenario – a variation of the master
scenario with different input
parameters
Example of the Document Viewer
Adding Scenarios and Groups
• New scenarios and groups can be
created easily in the Document
Viewer
• Options to duplicate existing groups
and scenarios or create new ones
Using the Add Scenario option to create a new
scenario
Using the Duplicate Group option to create a new group
Using the Duplicate Scenario option to create a new
scenario
Scenario and Group Management
• Scenario and group properties can
be altered in the Group and
Scenario Properties window
• This window allows users to alter
the name, colour and order of the
groups and scenarios
Groups and ScenarioProperties window
Viewing Scenarios
• Multiple scenarios can be
viewed at once using the Tile
Windows options
• The Synchronize Views
window allows users to
synchronize various viewing
options between scenarios
Editing Scenarios
• Changes to the external boundary
and material properties in the
master scenario are applied across
all of the scenarios in a group
• Edits to features such as water
table level, loading and supports
remain unique to each scenario
Multiple scenarios in a single Slide2 file
• Multi-scenario in Project Settings:
• Different Groups
• Different Scenarios
with:
• Different Seismic Loads
• Slope Angle Wizard
Slope Angle of
41o
Slope Angle of
34o
